Performance Evaluation of Outgoing Interface Selection Method on Fortigate SD-WAN for Network Optimization

https://doi.org/10.22219/kinetik.v10i2.2120
Mufti Kholil Romadhoni
Universitas Muhammadiyah Malang
Larynt Sawfa Kenanga
Universitas Muhammadiyah Malang
Denar Regata Akbi
Universitas Muhammadiyah Malang
Diah Risqiwati
Universitas Muhammadiyah Malang

Corresponding Author(s) : Denar Regata Akbi

dnarregata@umm.ac.id

Kinetik: Game Technology, Information System, Computer Network, Computing, Electronics, and Control, Vol. 10, No. 2, May 2025
Article Published : May 8, 2025

Share
WA Share on Facebook Share on Twitter Pinterest Email Telegram
  • Abstract
  • Cite
  • References
  • Authors Details

Abstract

Reliable and high-performance network services are essential to facilitate communication between parent companies and subsidiaries as well as among the subsidiaries themselves. Challenges arise in managing and optimizing outgoing interface selection in an effective and reliable Software-Defined Wide Area Network (SD-WAN) environment. This research evaluates four outgoing interface selection methods, namely Manual, Best Quality, Lowest Cost, and Maximize Bandwidth (SLA), using a tree-based network topology simulated in GNS3 with FortiGate devices as part of the simulation. The results show that under simulated disturbances, such as limiting a single connection line to 10 kbps, the Manual, Best Quality, and Lowest Cost methods perform worse than the Maximize Bandwidth method. In contrast, the Maximize Bandwidth method outperformed the others, achieving only 0% packet loss, 22.275 ms one-way delay, and 7.03 ms jitter, while maintaining the ITU-T G.1010 standard at the preferred level. These findings highlight the reliability and effectiveness of the Maximize Bandwidth method in ensuring consistent data transmission even under fault conditions, while providing practical guidance for network engineers in configuring SD-WAN for uninterrupted high-quality network services in complex business environments.

Keywords

SD-WAN Outgoing Interface Bandwidth Optimization Network Latency Network Stability
Kholil Romadhoni, M., Kenanga, L. S., Akbi, D. R., & Risqiwati, D. (2025). Performance Evaluation of Outgoing Interface Selection Method on Fortigate SD-WAN for Network Optimization. Kinetik: Game Technology, Information System, Computer Network, Computing, Electronics, and Control, 10(2). https://doi.org/10.22219/kinetik.v10i2.2120
